  • Pressure Sensor with thread PC12Ⅲ

Pressure Sensor with thread PC12Ⅲ

    Features

  Imported highly reliable pressure die

Compensation board filled with glue for protection against moisture

All stainless steel housing material

High accuracy, high reliability

12 months warranty period

Applications

  ■Glue

Environmental protection, chemical, coating

Polyurethane equipment

Industry standards supporting


Product Parameters

Electrical performance parameters

Pressure range

0100kPa6MPa


Pressure reference

Gauge pressure, Absolute pressure, Sealed gauge pressure


Excitation

1.5mA recommended for constant current; 10V for constant voltage.


Input impedance

Constant current: 2kΩ5kΩ; constant voltage: 3kΩ~12


Electrical connection

silicon soft wire


Compensation temp.

-1070


Operating temp.

-40120


Storage temp.

-40120


Insulation resistance

≥200MΩ/250VDC


Response time

≤1ms (up to 90%FS)


Measured medium

All the liquids and gases compatible with 316L.


Mechanical vibration

20g (205000Hz)


Shock

20g(20~5000HZ


Service life

10×106 (cycles)



Production process

PC12Ⅲ Flush Diaphragm Pressure Sensor with thread


                                          Testing Equipment



PCDO20 Digital Analyzer MonitorPCDO20 Digital Analyzer Monitor

Certificate

PC12Ⅲ Flush Diaphragm Pressure Sensor with thread
